Steel-Wood Fire Door with Vision Panel

FIRE DOOR HARDWARE IS AN INTEGRATED LIFE-SAFETY SYSTEM.

COMPONENTS WORK TOGETHER TO ENSURE THE DOOR CLOSES RELIABLY,

LATCHES SECURELY, AND SEALS EFFECTIVELY AGAINST SMOKE AND FLAMES DURING A FIRE.

FIRE DOOR HARDWARE IS AN INTEGRATED LIFE-SAFETY SYSTEM.

COMPONENTS WORK TOGETHER TO ENSURE THE DOOR CLOSES RELIABLY,

LATCHES SECURELY, AND SEALS EFFECTIVELY AGAINST SMOKE AND FLAMES DURING A FIRE.

Protect what matters most, designed to resist flames, smoke, and extreme heat, LHSH doors provide critical escape time while enhancing your security and aesthetic appeal. 30/60/90/120-min fire resistance, certified to delay fire spread, keeping your safety. Choose from modern, classic, or minimalist designs (wood, steel, glass options) from green-certified materials to smart fire solutions, we innovate because lives depend on it. LHSH steel fire doors are precision-crafted to provide superior fire resistance, security, and durability. Tested to withstand temperatures exceeding 1000°C, these doors deliver certified protection when every second counts.

INSTALLATION METHOD	Single/Double/Unequal Door	FIRE RESISTANCE RATING
MATERIAL	Galvanized steel sheets (0.4–1.2 mm thick) bonded to + wood frames for structural strength.	EN Standards
FILLING MATERIAL	Fire-retardant treated timber (e.g., pine, fir) filled with non-combustible mineral wool or fire-resistant honeycomb.	EI30/EI60/EI90/EI120‌
FIRE RATED TIME	30/60/90/120 minutes	(Integrity + Insulation for 30/60/90/120 minutes)
SIZE	Up to 9'- 5.7" x 10'-2.2" ft (height) \| 2888 x 3104mm (height)	BS Standards
SEALING SYSTEM	Intumescent seals (expand at 200°C+ to block smoke/flames) + smoke seals (cold smoke protection).	FD30/FD60/FD90/FD120‌
ACOUSTIC PERFORMANCE	Sound insulation up to 30–40 dB (STC/Rw rating).	(Fire duration rating)
THERMAL INSULATION	U-value: 1.0–1.8 W/m²K (enhances energy efficiency)	GB Standards
OPENING DIRECTION	Swing Inward / Outward	Class A fireproof door
COLOR	RAL color system, could be customized as well.	Fire resistance insulation > = 1.5hours
ACCESSORIES	Lock, handle, hinges,door closer,panic bar and other as requested.	Fire resistance integrity > = 1.5hours
VISION PANEL	With or without as requested. (Fire proof glass)	Class B fireproof door
LITE FRAME	Frame type can be customized	Fire resistance insulation > = 1.0hours
LOUVER	With or without as requested.	Fire resistance integrity > = 1.0hours
FEATURE	Fire proof and thermal insulation.	Class C fireproof door
APPLICATION	building project, company, home, office, hotel, church, Just Anywhere you want!	Fire resistance insulation > =0.5 hours
PACKAGE	Inside: PE paper \| Outside: double layers carton box and wooden pallets.	Fire resistance integrity > =0.5hours

Wooden Fire Door with Glass
