Price Of Hidden Aluminum Wood Doors

Combination of hidden aluminum strength, stunning wood aesthetics, minimalist design

and functional benefits makes these doors a top-tier choice for sophisticated interiors.

① TARGET AUDIENCE

Renovators Seeking Premium, Modern Solutions, Architects, Interior Designers,

High-End Residential Builders,Luxury Homeowners, Boutique Commercial Projects (Hotels, Offices)

② CORE ADVANTAGES

Structural Integrity, aluminum frame ensures dimensional stability (RH 30–70%).

Seamless Aesthetics, hidden hardware + flush edges = minimalist visual continuity.

Acoustic Performance, integrated seals achieve up to Rw 35 dB sound reduction.

Durability, aluminum resists corrosion; wood surfaces protected by embedded frame.

Precision Engineering, CNC machining ensures consistent reveals (±0.5mm tolerance).

③ CORE PARAMETERS

Door Thickness    | 40mm – 45mm (standard) / Up to 60mm (custom) |

Door Leaf Width   | 700mm – 1200mm (single leaf) / Custom widths available |

Door Leaf Height | 2000mm – 2600mm (standard) / Custom heights available |

Frame Profile Depth | 30mm – 50mm (concealed within door leaf)|

Reveal (Shadow Gap) | 3mm – 8mm (visible gap when closed)|

Weight Capacity | Up to 80–120 kg (dependent on hinge/pivot system)|

Acoustic Rating | Rw 28 dB – 35 dB (with integrated seals)

Fire Rating | Typically Class E / 20-30 mins (varies by core material & certification)|

Surface Material | Solid wood / Veneer (Oak, Walnut, Ash, Teak, etc.)|

Core Material | Engineered wood (MDF, HDF), Honeycomb, Solid wood staves|

Aluminum Alloy | 6000-series (e.g., 6063-T5/T6) – Anodized or powder-coated|

|Hardware Type | Concealed pivot hinges / Invisible barrel hinges|

④ CONSTRUCTION FEATURES

Integrated Aluminum Frame

High-strength extruded aluminum alloy frame fully embedded within the door leaf.

Provides structural rigidity while eliminating visible perimeter stiles/rails on the door face.

Flush Edge Construction

Ultra-slim, consistent aluminum edge banding (0.8–1.5mm) creates a seamless,

monolithic appearance. No protruding edges; clean lines align perfectly with walls/jambs.

Concealed Mounting System

Barrel Hinges:Fully hidden within door edge and jamb (no visible knuckles).
